3.2V 4Ah 26700 LiFePO4 Cells
Model: LNC26700-4000
Nominal Voltage: 3.2V
Nominal Capacity: 4000mAh
Material: LFP
3.2V 4.0Ah 26700 LiFePO4 Cell
| Items | Specification | Remark |
|---|---|---|
| Nominal Capacity | 4.0Ah | 0.5C@25ºC± 2ºC |
| Minimum Capacity | 3.96Ah | 0.5C@25ºC± 2ºC |
| Nominal Energy | 12.8Wh | 0.5C@25ºC± 2ºC |
| Nominal Voltage | 3.2V | |
| Maximum Charge Voltage | 3.65V | |
| Limited Charging Voltage | 3.65V | |
| Discharge Cut-off Voltage | 2.0V | |
| Internal Resistance(AC) | ≤20mΩ(AC) | 1KHz |
| Internal Resistance(DC) | ≤35mΩ(DC) | 25ºC,50%SOC, 2C(8A) discharge for 10s |
| Standard Charge Current | 0.5C (2A) | |
| Standard Discharge Current | 0.5C(2A) | |
| Maximum Continuous Charge Current | 2C(8A) | Not for cycle |
| Maximum Continuous Discharge Current | 3C(12A) | Not for cycle |
| Standard Charge Mechod | At 25ºC±2ºC,0.5C(2A) constant current(CC) charge to 3.65V, followed by 3.65V constant voltage(CV) charge until current taper to 0.05C(0.2A). | |
| Standard Discharge Method | At 25ºC±2ºC, discharge with 0.5C(2A) constant current, 2.0V cut-off. | |
| Operating Temperature | Charge: 0ºC~55ºC; Discharge: -20ºC~60ºC. | |
| Storage Temperature | Less than 1 year: -20ºC~25ºC; Less than 3months: -20ºC~45ºC. | 40%~60%SOC storage |
| Dimension | Height: 71±0.2mm; DIameter: 26.4±0.2mm | |
| Weight | 90±3g | |
More, pls contact us to get detailed specifications!
- High Safety
- High Energy Density
- Long Cycle Life
- Excellent Thermal Stability and Safety
- Faster Charging Capabilities
- High Current Discharge Capability
- Environmental Friendliness
- Wide Operating Temperature Range
- Cost-Effectiveness
26700 LiFePO4 Cell is a versatile battery with a wide range of applications, including electric vehicles, energy storage, renewable energy systems, industrial equipment, portable power systems, and more. Its safety, long lifespan, and energy efficiency make it a preferred choice in many industries.
Home Solar Energy Storage
Solar Lightings
Protable Power Bank
Electric Two-Wheeler Vehicle(2W-EV)
Automated Guided Vehicle (AGV)
Golf Cart
- Products Certifications: CCC/GBT31484/GBT31485/GBT31486/BIS/CE/Rohs/PSE/UL1642/BSMI/CB IEC62133/CB IEC62619/UN38.3/MSDS
- Factory Certifications: 1, Quality Management System: ISO9001 Quality System / IATF16949 Quality System 2,Environmental Health System: ISO14001 & ISO45001 Environmental and Occupational Health Management Systems. 3,Green and Low-Carbon Certification: ISO14064 standards
