3.7V 3600mAh 124060 Rechargeable LiPo
Type: Li Polymer battery
Model: LNC124060
Nominal Voltage: 3.7V
Nominal Capacity:3600mAh
Max Dimensions(T*W*L): 12.2*40.5*62(mm)
Product Overview
The LNC124060 is a 3.7V 3600mAh lithium polymer battery designed for portable electronic devices requiring high energy density, compact dimensions, and reliable rechargeable power performance.
With a compact pouch cell structure and stable charging and discharging characteristics, this LiPo battery provides an efficient power solution for applications requiring extended operating time and optimized space utilization.
LNC supports customized lithium polymer battery solutions, including battery dimensions, capacity, connectors, and battery pack integration to meet different application requirements.
Product Specification
| Parameter | Specification | Condition |
|---|---|---|
| Battery Model | LNC124060 | – |
| Cell Type | Lithium Polymer Battery | – |
| Product Size | 12.2 × 42.5 × 62 mm | – |
| Nominal Voltage | 3.7V | – |
| Nominal Capacity | 3600mAh | 0.2C discharge |
| Energy | 13.32Wh | – |
| Charging Voltage | 4.2V | CC/CV Charging |
| Standard Charging Current | 0.2C | Standard Charge |
| Maximum Charging Current | 0.5C | Maximum Charge |
| Standard Discharge Current | 0.2C | Standard Discharge |
| Maximum Discharge Current | 0.5C | Maximum Discharge |
| Charging Temperature | 0°C to 45°C | – |
| Discharge Temperature | -20°C to 60°C | – |
| Protection Functions | Overcharge Protection, Over-discharge Protection, Overcurrent Protection, Short Circuit Protection | With Protection Circuit |
| Battery Weight | 65.8g | Approx. |
Product Advantages
High Capacity Performance
Provides longer operating time for portable devices requiring reliable and continuous power supply.
High Energy Density
Lithium polymer pouch technology delivers efficient energy storage in a compact battery structure.
Stable Performance
Designed with consistent charging and discharging characteristics for dependable daily operation.
Compact Pouch Design
Flexible pouch cell structure enables efficient integration into portable and space-limited devices.
Applications
The LNC124060 3.7V 3600mAh lithium polymer battery is suitable for portable and smart electronic devices requiring compact size, high energy density, and reliable rechargeable power performance.
Portable Electronics
Provides reliable power for handheld devices, portable equipment, and electronic products requiring extended operating time.
Medical Devices
Suitable for portable medical equipment requiring stable power output and compact battery integration.
IoT & Smart Devices
Supports smart terminals, sensors, and connected devices requiring efficient energy storage solutions.
Industrial Equipment
Provides dependable rechargeable power for handheld instruments and compact industrial devices.
OEM/ODM Battery Solutions
LNC provides customized lithium polymer battery solutions for different application requirements.
From battery selection to customized battery pack development, we support customers with flexible OEM and ODM services.
Custom Battery Design
Support customized battery size, capacity, voltage, and structure based on product requirements.
Battery Pack Integration
Provide complete battery solutions including cell selection, assembly, protection circuit, and testing.
Quality & Technical Support
Support customers with battery evaluation, customization guidance, and reliable production solutions.
Request A Quote
Looking for a reliable 3.7V 3600mAh lithium polymer battery solution for your project?
Contact LNC for battery specifications, customization options, and OEM/ODM support.
Our team can help you select the right LiPo battery solution based on your application requirements.
