10840 600mAh 3.7V Li-ion recharable batteries for Laser Pen, Mini Flashlight Pen, Dental Pen Light

Model: LNC10840-600

Nominal Voltage: 3.7V

Nominal Capacity: 600mAh

Material: Li-ion

Contact us

10840 600mAh 3.7V Li-ion recharable batteries for Laser Pen, Mini Flashlight Pen, Dental Pen Light

Basic information:

10840 600mAh 3.7V Li-ion recharable batteries for Laser Pen, Mini Flashlight Pen, Dental Pen Light
  • Model Number: 10840C-600mAh
  • Dimensions: 10.3 X 84.0mm
  • Internal Resistance: Max 65mΩ
  • Weight: 17±2g
  • Cap: Flat/Pointed
  • Standard Charging: CC/CV, 0.2C5A, 4.20V
  • Standard Discharge: CC, 0.2C, 3.00V
  • Charging Time: 8.0 hours (standard charging)
  • Fast Charging: 600mA @1.0C
  • Fast Discharge Current: 1200mA @2.0C
  • Max Discharge Current: 1800mA @3.0C
  • Applications: Power Bank, Mobile Devices, Wireless DV Cameras, Barcode Scanners, High-Intensity Flashlights, Bluetooth Speakers, Lights, Personal Care Devices, etc.

Other models

ModelVoltage(V)Capacity(mAh)Diameter(mm)Height(mm)
10150-803.7801015
10180C-1003.71001018
10280C-1603.71601028
10300-2003.72001030
10380-2003.72001038
10380C-2503.72501038
10400-3003.73001040
10440-3203.73201044
10840-6003.76001084
13300-4003.74001330
14250T-2503.72501425
14280C-3203.73201428
14330-6503.76501433
14500-8003.78001450
14500C-6503.76501450
14500HP-6503.76501450
14650-12003.712001465
14650H-9003.79001465
16340C-7003.77001634
16340HP-6003.76001634
16500C-12003.712001650
16500HP-8003.78001650
16650-20003.720001665
18350-11003.711001835
18350-8503.78501835
18350HP-7003.77001835
18500-16003.716001850
18650-15003.715001865
18650-2000-10C3.620001865
18650-2000-8C3.620001865
18650-2500-3C3.725001865
18650-2500-8C3.625001865
18650-2600-3C3.726001865
18650-2600-5C3.626001865
18650-3000-5C3.630001865
18650-3350-3C3.633501865
18650F-25003.725001865
18650T-25003.725001865
21700-4000-5C3.640002170
21700-4000-8C3.640002170
21700-4500-3C3.645002170
21700-5000-3C3.650002170
22430-20003.720002243
22500-24003.724002250
22650-30003.730002265
26500-32003.732002650
26500HP-20003.720002650
26650-50003.750002665
26650HP-34003.734002665
32550-50003.750003250
32600-55003.755003260
32650-65003.765003265
34600-70003.770003460

Applications

•Elecommunications: Audio&vidio Devices,laptop, GPS, POSmachines , E-Bike,E V, GPS, POSmachines, smart robot, miner lamps,etc

 •Medical equipment: B-machine, ECG machine, monitor, ventilator, anesthesia machine, infusion pump, etc.

•Customized Smart Robot: Industrial Robot, Service Robot, Educational Robot, Clean Robot, Entertainment Robot.

•Financial equipment : POS machine, mobile payment, micro printer, bar code scanner, miniature projector, etc.

•Energy storage: solar panel, wind, electricity, UPS, backup power, AGV, yachts, outdoor portable power, etc.

Advantages

•High energy density and light weight

•Low self-discharge rate and low impedance rate

•No memory effects

•Wide operating temperature range, batteries can be charged over a temperature range of 0°C to 45°C,                                                         and discharged between -20°C to 60°C

•Long cycle life, higher than 80% of the initial capacities of batteries after 500 cycles

Factory

BMS Testers

Battery Sorting Machines

Automatic Spot Welding Machines

Battery Aging Equipment

Integrated Testing Instrument

Vibration Testing Machine

Overcharge and Impact Testing

High-Low Temperature Test Chamber
