High Performance 3.6V 2500mAh 30A 18650 Li-ion Cell −40°C~85°C
Model: LNC-18650W
Nominal Capacity: 2500mAh
Nominal Voltage: 3.60V
Max Continuous Discharge Current: 30A
High Performance 3.6V 2500mAh 30A 18650 Li-ion Cell −40°C~85°C
Product specifications
| Category | Item | Specification |
|---|---|---|
| Dimension | Diameter | 18.3 ± 0.2 mm |
| Height | 64.95 ± 0.2mm | |
| Capacity | Min Capacity (0.2C) | 2450 mAh |
| Typical Capacity (0.2C) | 2500 mAh | |
| Rate Capacity | ≈2450mAh（20A） | |
| Voltage and Current | Nominal Voltage | 3.60 V |
| Working Voltage | 2.75 V – 4.20 V | |
| Max Charge / Discharge Current | 2.5A /30 A | |
| Working Temperature | Charge | −20 °C ~ 60 °C |
| Discharge | −40 °C ~ 85 °C | |
| Other | Cycle Life | > 300(70%) cycles |
| −40 °C Capacity (0.2C) | ≈ 50 % | |
| Recovery Capacity after 1000 h Aging | >95 %(80 °C) |
