7.4V 2Ah 18650 Li ion Battery Pack 2S1P
Model: LNC-Q7.4V2AH
Nominal Voltage: 7.4V
Nominal Capacity: 2Ah
Material: Li ion
7.4V 2Ah 18650 Li ion Battery Pack 2S1P
| Item | Specification |
|---|---|
| Nominal Voltage | 7.4V |
| Nominal Capacity | 2Ah |
| Rated Energy | 14.8Wh |
| Charging Voltage | 8.4V |
| Operating Voltage Range | 5.6V - 8.4V |
| Standard Charging Current | 0.2C |
| Maximum Charging Current | 2A |
| Standard Discharge Current | 0.2C |
| Max Continuous Discharge Current | 2A |
| Cutoff Discharge Voltage | 5.6V |
| Storage Temperature | -20°C to 45°C |
| Charging Temperature | 0°C to 45°C |
| Discharge Temperature | -20°C to 60°C |
| Connector | XH2.54 2P |
| External Dimensions | 68*37.5*18.8 mm |
| Cell Configuration | ICR18650-2AH-2S1P |
•High energy density and light weight
•Low self-discharge rate and low impedance rate
•No memory effects
•Wide operating temperature range, batteries can be charged over a temperature range of 0°C to 45°C, and discharged between -20°C to 60°C
•Long cycle life, higher than 80% of the initial capacities of batteries after 500 cycles
