25.9V 9Ah 7S3P 18650 Li-ion Battery High Capacity Rechargeable Li-ion 18650 Battery Pack
Model: LNC-02Q25.9V9AH
Nominal Voltage: 25.9V
Nominal Capacity:9Ah
Material: Li ion
Product Specification
25.9V 9Ah 7S3P 18650 Li-ion Battery High Capacity Rechargeable Li-ion 18650 Battery Pack
| Item | Specification |
|---|---|
| Nominal Voltage | 25.9V |
| Nominal Capacity | 9Ah |
| Rated Energy | 233.1Wh |
| Charging Voltage | 29.4V |
| Operating Voltage Range | 19.6V – 29.4V |
| Standard Charging Current | 0.2C |
| Maximum Charging Current | 15A |
| Standard Discharge Current | 0.2C |
| Max Continuous Discharge Current | 30A |
| Cutoff Discharge Voltage | 19.6V |
| Storage Temperature | -20°C to 45°C |
| Charging Temperature | 0°C to 45°C |
| Discharge Temperature | -20°C to 60°C |
| Connector | Customization |
| External Dimensions | 135*60*69(mm) |
| Cell Configuration | ICR18650-9AH-7S3P |
Custom Li Ion Battery Packs
We offer customized services tailored to your needs.
The capacity and dimension can be customized according to your request:
1. Customized battery size and shell material.
2 . Customized protection board charging and discharging current.
3. Customized connect plug and socket, connector wire.
Applications
Product Advantages
•High energy density and light weight
•Low self-discharge rate and low impedance rate
•No memory effects
•Wide operating temperature range, batteries can be charged over a temperature range of 0°C to 45°C, and discharged between -20°C to 60°C
•Long cycle life, higher than 80% of the initial capacities of batteries after 500 cycles
