12V 1.5Ah 3S1P Rechargeable Lithium-ion Battery Pack for Solar Systems
Model: LNC-Q12V1.5AH
Nominal Voltage: 11.1V
Nominal Capacity: 1.5Ah
Material: Li ion
12V 1.5Ah 3S1P Rechargeable Lithium-ion Battery Pack for Solar Systems
| Item | Specification |
|---|---|
| Nominal Voltage | 11.1V |
| Nominal Capacity | 1.5Ah |
| Rated Energy | 16.65Wh |
| Charging Voltage | 12.6V |
| Operating Voltage Range | 8.4V - 12.6V |
| Standard Charging Current | 0.2C |
| Maximum Charging Current | 1C |
| Standard Discharge Current | 0.2C |
| Max Continuous Discharge Current | 1C |
| Cutoff Discharge Voltage | 8.4V |
| Storage Temperature | -20°C to 45°C |
| Charging Temperature | 0°C to 45°C |
| Discharge Temperature | -20°C to 60°C |
| Connector | XH2.54 2P |
| External Dimensions | 69.4*56.2*19.2 mm |
| Cell Configuration | ICR18650-1.5AH-3S1P |
•High energy density and light weight
•Low self-discharge rate and low impedance rate
•No memory effects
•Wide operating temperature range, batteries can be charged over a temperature range of 0°C to 45°C, and discharged between -20°C to 60°C
•Long cycle life, higher than 80% of the initial capacities of batteries after 500 cycles
